Independent machinery sourcing · RFQ
Industrial Conveyor System Sourcing is an independent sourcing partner for US buyers who need an industrial conveyor system with named belt width in mm, conveyor length in mm, load in kg and speed in m/min restated by the factory. Share quantity and destination so we can request comparable factory wholesale quotes. This site does not sell from stock and does not claim original-equipment identity. A published modular-belt example such as loads up to 150 lbs (68 kg) on an open manufacturer sheet dated 2026-09-17 is a unit check, not this service’s supply promise. Adjacent equipment families are out of scope here.
Request Factory Quotes
Send the lightest and heaviest SKUs, the smallest product footprint at each transfer, underside shape and photographs of bags or unstable bottles rather than describing everything as cartons.
Ask the factory to run those SKUs at the planned spacing, incline and speed, then block the discharge to show what happens when the downstream machine stops accepting product.
Record tipped, trapped and scuffed products over repeated starts. Unloaded belt speed is not the production comparison; use accepted transfers per minute under the stated duty cycle.
An industrial conveyor system RFQ is useful when format range, replaceable guides and first-good checks are written before factories guess. Changeover between cartons and bags is a documented duty, not an assumed free option. We collect those splits so manufacturers quote the same envelope rather than mixing a single belt section with a warehouse system.
Name the next SKU length, width, height and center of gravity. Side guides, nose geometry and transfer tooling often change even when belt width in mm stays the same. Feedstock here is the moving product, not a process fluid.
Ask which belts, flights, wear strips, photo-eyes and transfer plates the supplier treats as included versus consumable after a format change. Those items belong on the spare parts and tooling lines.
Use the lightest and heaviest formats at planned spacing after restart. Cycle time must include recovery from a blocked discharge, not only continuous running. Positioning at the next machine is judged on the actual transfer, not on an unloaded belt.
Belt, frame, drive, supports and named transfer hardware, quoted as equipment until the supplier lists extras such as accumulation zones, indexing or a control cabinet.
Packing, ocean or domestic freight, duties and insurance to the stated US destination remain separate lines unless the factory writes them into the same total.
Foundations, three-phase supply, compressed air drops, PLC interface work, installation, training and spare parts sit on site-cost lines.
List the smallest length and width that must survive the nose, plus underside shape. A carton that rides the belt can still fail at a gap that is larger than that footprint.
Ask for a drawing showing nose geometry, guide termination, speed matching and the receiving surface. A raised cleat that works on an incline may complicate a close transfer.
Count tipped and trapped products over repeated starts. FAT language stays on the named supplier contract; this page only lists the trial questions.
The buyer supplies SKU dimensions, load distribution, destination and whether accumulation is required. The factory restates belt width, length, load, speed and included transfers. Industrial Conveyor System Sourcing coordinates comparable quotes; engineering acceptance remains between buyer and named supplier. SAT travel is extra unless written in.
